Product Details
＋
The Ortur LM3 LE will save you 1/3 of the time thanks to its 15.000mm/min engraving speed. It has been designed with high-quality silent motor that reduces vibration and noise to prolong motor life.
Minimalism on Appearance
Ortur LM3 LE only retains the Home button on its frame. More compact body design without changing the engraving area to save open space. Deep night black color. a cooler option.
Adopt TMC2209 silent drive. with 256 times high subdivision. no noise and vibration when the motor rotates.
Free from sophisticated desaturate processes. saving time. energy and more RAM space.
What's in the box?
1xOrtur LM3 LE Laser Engraving & Cutting Machine
Specifications
| Laser Machines | Ortur Laser Master 3 | Ortur Laser Master 3 LE | Ortur Laser Master 3 LE | Ortur Laser Master 3 LE |
|---|---|---|---|---|
| Laser Module | LU2-10A | LU2-10A | LU2-4LF | LU2-4SF |
| Structure | Fully-enclosed | Semi-enclosed | Semi-enclosed | Semi-enclosed |
| Speed | 20.000mm/min | 15.000mm/min | 15.000mm/min | 15.000mm/min |
| Size | 660*588*150mm | 614*588*128mm | 614*588*128mm | 614*588*128mm |
| Engraving Area | 400*400mm | 400*400mm | 400*400mm | 400*400mm |
| Extended Engraving Area | 400*850mm | Coming Soon | Coming Soon | Coming Soon |
| Output Power | 9.5-10.5W | 9.5-10.5W | 4.5-5.5W | 4.5-5.5W |
| Electrical Power | 40W | 40W | 20W | 20W |
| Laser Wavelength | 445 5nm | 445 5nm | 445 5nm | 445 5nm |
| Spot Size | 0.05*0.1mm | 0.05*0.1mm | 0.17*0.25mm | 0.12*0.15mm |
| Spot Mode | Square Spot | Square Spot | Square Spot | Square Spot |
| Focal Distance | 50mm | 50mm | 50mm | 30mm |
| Main Material | Aluminum PC | Aluminum PC | Aluminum | Aluminum |
| Laser Level | Class IV | Class IV | Class IV | Class IV |
| Service Life | >10.000h | >10.000h | >10.000h | >10.000h |
| Safety Protections | 7 | 5 | 5 | 5 |
| Support Function | WIFI/APP/USB/SD Card | WIFI/APP/USB/TF Card | WIFI/APP/USB/TF Card | WIFI/APP/USB/TF Card |
