Ultraloq U-Bolt Series
The Ultraloq U-Bolt Series reimagines everyday security with a sleek. minimalist design packed with cutting-edge technology. Unlock your door five different waysfingerprint. smartphone. PIN code. voice control. or even the good old-fashioned key. With a weatherproof build and ANSI Grade 1 certification. this lock is as tough as it is intelligent.
Perfect for everyday convenience. the Bluetooth base model gives you keyless entry via smartphone. passcodes. or even mechanical keys. Using the Ultraloq app. you can unlock your door with a tap. set user-specific codes. and view access logsall via Bluetooth. It's ideal for those who want smart control at their fingertips without relying on Wi-Fi.
The Built-in Wi-Fi model gives you total control from anywhere in the worldno additional hub or bridge is required. Lock and unlock remotely. receive instant notifications. and enable voice assistant integration with Alexa or Google Assistant. The Z-Wave edition goes a step further for smart home enthusiasts. offering compatibility with hubs like SmartThings. Hubitat. or Ring Alarm for deep automation and integration. Both models include a smart auto-lock feature and door sensor support. so your door knows when to lock itselfand you never have to wonder again.
Whether you opt for the Bluetooth base model or go all out with the Built-in Wi-Fi or Z-Wave edition. the U-Bolt makes sure your door is smarter than everwith auto-lock. remote access. and real-time alerts that give you complete control from anywhere.
Highlights:
5 unlock methods: fingerprint. code with anti-peep. smartphone (Bluetooth). shake to open via Apple Watch. and mechanical key
Comes in Bluetooth-only. Bluetooth Wi-Fi Bridge. built-in Wi-Fi. or ZWave WiFi Bridge variants
Only the builtin WiFi and ZWave options include a door sensor for autolock/unlock and open/closed status
ANSI/Grade1 rated and IP65rated for allweather use
Fits standard doors (11). reversible handing. powered by 4AA batteries (typically ~1year on Bluetooth/ZWave; WiFi lasts 36months)
Supports up to 60 users and 50 PIN
Control from anywhere
Extensive connectivity
Smart home integration- Works with your favorite smart home platform like Alexa. Google Home. SmartThings. IFTTT
Dual data encryption
DIY installation
SPECIFICATIONS:
Physical & Storage
Hardware type: Deadbolt
Mechanical Key Override: Yes
Case Material: Premium Zinc Alloy
Weight: 3.3 lb / 1.5 kg
Finish:
2.95 x 4.92 x 1.39 inch / 75 x 125 x 35.3 mm (back panel)
2.95 x 2.95 x 0.98 inch / 75 x 75 x 25 mm (front panel)
Working Temperature
Outside lock body: -22 F (-30 C) to 149 F (65 C) IP65 Rated
Inside lock body: 14 F (-10 C) to 131 F (55 C)
Storage
Users: 50
Codes: 50
Power
Working Voltage: 6V (4 X Alkaline AA batteries)
Battery Life: U-Bolt. U-Bolt Bridge. U-Bolt Z-Wave: Up to 1 year; U-Bolt Wi-Fi: 3-6 months
Connectivity & Integration
Connectivity: Standard Bluetooth. optional Wi-Fi (2.4GHz. 802.11 b/g/n) or Z-Wave Plus (908.4 MHz. 916 MHz)
Compatible Smartphone: iOS and Android
Compatible Smart Home Eco-system: Alexa. Google Assistant. IFTTT. SmartThings
Installation & Warranty
Door Prep: 2-1/8-inch (54 mm) diameter face hole & 1-inch (25 mm) diameter latch hole
Door Thickness: 1.375 - 1.75 (35-45mm)
Door Handing: Reversible
Backset: Adjustable to 2-3/8 inch or 2-3/4 inch
Warranty: 18 months electronic warranty and lifetime mechanical warranty
WHAT'S IN THE BOX:
1 x Exterior Keypad Assembly
1 x Interior Thumb-turn (motor) Unit
1 x Smart Deadbolt Latch (adjustable 23/8 or 23/4 backset)
1 x Strike Plate Mounting Screws
1 x WiFi Bridge (only included in Bluetooth and Wi-Fi Bridge Version & Z-Wave Wi-Fi Bridge Version)
4 x AA Batteries
1 x Installation Manual
1 x Warranty Card
1 x Mechanical Backup Key(s)
